NAD Electronics began 40 years ago with what was then a different business model from that employed by their hi-fi competitors. The electronics were designed in England, but manufacturing was farmed out to firms in Taiwan with lower labor costs -- a model that is now the norm in the audio industry. NAD quickly developed a reputation for good performance and strong value that they’ve maintained in the decades since then. Today, NAD’s product development is a collaboration between engineers in Canada, England, and Hong Kong, with manufacturing in mainland China. Although NAD is still committed to offering a variety of products at modest prices, a few years ago they decided to take their engineering, build quality, and pricing more upscale, and launched the Masters Series components. With these models, they hope to retain their loyal customers as their ambitions grow, and perhaps attract some new ones who may not have been considering the brand.
The Masters M51 Direct Digital digital-to-analog converter ($1999 USD) is based on the same CSR Direct Digital Feedback Amplifier chip used in the Masters M2 Direct Digital integrated amplifier. Rather than the pulse-width modulated (PWM) bitstream switching 50V rails, as in the M2, the CSR chip is coupled to an output stage that delivers 4.75V RMS to the balanced outputs and 2.375V to the single-ended. All incoming PCM data is converted to a 7-bit/844kHz PWM signal, with mathematical operations carried out to 35-bit precision. The PCM-to-PWM conversion and the width of the pulses are controlled by a master clock running at 108MHz. The analog output is compared with a reference PWM signal, and any corrections are made in the digital domain. (This correction loop is why it is called a Direct Digital Feedback Amplifier.)
The M51 is a full-size component measuring approximately 17"W x 3"H x 12"D and weighing just shy of 13 pounds. The case is primarily stamped steel, with a dark-gray powder coat and a faceplate of 3/4"-thick aluminum milled to curve back toward the sides. The look and feel are of quality but not opulence. The front panel’s central display gives the input, incoming sample rate, and volume setting. The only controls are a power/standby button and a button that cycles through the available sources. Direct source selection, signal polarity, and volume control are available only from the remote control. Around back is a bevy of connectors: AES/EBU, coaxial, and optical digital inputs, an asynchronous USB input, and the standard IEC power inlet. All inputs accept sample rates up to 192kHz. (Windows users must download an ASIO driver from NAD’s website for the USB input to support sample rates above 96kHz.) The M51’s most unusual feature is the presence of two HDMI inputs, so that it can accept uncompressed stereo audio data from a Blu-ray player or other device. (Multichannel audio is not supported.) There is also an HDMI output that allows video signals to pass through the M51. (NAD suggests that the M51 could be used for a high-quality, two-channel home-theater setup.) There are 12V in and out triggers and an RS-232 port for system integration, along with another USB connection for firmware updates. Analog outputs are available on both XLR and RCA connections.
The presence of a digital volume control suggests that you run the M51 directly into your power amplifier. Since the volume control operates in the 35-bit domain, no bit truncation will occur with 24-bit sources until you reach 66dB of attenuation -- really, really quiet. Greg Stidsen, NAD’s director of technology, advises those using the M51 as a source into a typical preamplifier or integrated amp to set the volume control to -1dB rather than 0dB, as that level has better distortion performance. The measured output of this volume setting for a full-scale sinewave -- a shade over 4.2V balanced and 2.1V unbalanced -- was also very close to that of my reference CD player, the Ayre Acoustics C-5xeMP universal two-channel disc player.
For this review, I ran the NAD’s balanced outputs into my Graaf GM-50 integrated amplifier, and also listened with the M51’s single-ended outputs run into my Woo Audio GES electrostatic headphone amplifier. CD data were fed to the NAD via an AES connection from the Ayre. Higher-resolution data came over USB from my laptop running Windows Vista and, alternately, foobar2000 and JRiver Media Center. I also tried a few ripped CDs to compare the AES and USB performance, but heard no significant difference.
Sound
One of the challenges in reviewing DACs is that so many of them sound so similar to each other. That may be, at least in part, because most of them are based on a relatively small number of DAC chips. Whether it was due to the Zetex chip at its heart or some other aspect of its design, the Masters M51 had a character different from that of other DACs of my recent experience. It sounded relaxed, soft, and, tonally, a little on the warm side of strict neutrality. The M51’s sound was the antithesis of the hard, brittle, edgy qualities that some audiophiles have ascribed to digital over the past three decades.
This forgiving disposition took the sting out of early tape-to-digital transfers -- such as the 1990 version of Sade’s Diamond Life (CD, Portrait RK 39581). Many of today’s mainstream pop releases also benefit from a little tempering. Adele’s voice in "Rolling in the Deep," from her 21 (16/44.1 FLAC, XL Records), retained the searing quality that’s part of the song’s style, but the tambourine had less bite and the cymbals less sizzle than usual. It’s not that the M51 turned these far-from-perfect recordings into sonic spectaculars; it just made their flaws less obvious and irritating. Carlos Santana and John McLaughlin’s Love Devotion Surrender (CD, Columbia CK 63593) isn’t ruthlessly compressed or a particularly bad transfer, but I usually find it a little fatiguing when I play it at levels appropriate for this type of music -- i.e., room-fillingly loud. Again, the NAD let me listen through the entire album without strain.
There was, however, a downside to this easygoing nature. Mark Walker’s hi-hat work in "The Peanut Vendor," from Paquito d’Rivera’s Portraits of Cuba (24/96 FLAC, Chesky/HDtracks), was a little hazy where I know it can sound more realistically metallic. Although I appreciated being able to listen to the Santana-McLaughlin album without a headache, the M51’s rendition lacked some of the drive and energy I want from rock music. Classical music, too, often benefits from a more exacting sound. When I listened to pianist Ronald Brautigam’s recording of Mozart’s Piano Concertos Nos. 17 and 26, with Michael Alexander Willens leading the Cologne Academy (24/96 FLAC, BIS/eclassical), the NAD’s relaxed delivery made the ensemble’s playing seem a little loose and inattentive.
Some music is meant to sound relaxed. Eva Cassidy’s charming and intimate Simply Eva (CD, Blix Street G2-10099) suffered not at all; the M51 communicated her phrasing with great fluidity, painting both voice and guitar in warm, mellow tones. The NAD also captured the easy sense of swing in the Oscar Peterson Trio’s Night Train (24/96 FLAC, Verve/HDtracks). Ray Brown’s bass exhibited a little more bloom than I’m accustomed to hearing, but individual notes never blended into each other.
Speaking of bass . . . the M51 delivered substantial weight and body with lower-register instruments -- whether acoustic or electric bass, or tuba and contrabassoon in Kalevi Aho’s concertos for each of the latter, as respectively performed by soloist Øystein Baadsvik with Mats Rondin conducting the Norrköping Symphony Orchestra; and by soloist Lewis Lipnick with Andrew Litton conducting the Bergen Philharmonic (CD, BIS 1574). Moving even further down the audioband, the NAD made orchestral bass drums sound big, and provided the necessary foundation to the organ in Jan Lehtola’s recording of Aho’s Symphony for Organ (24/96 FLAC, BIS/eclassical). Some other DACs give a firmer attack to bass notes, but the M51 didn’t really lack in this regard. Through it, the kickdrum on Adele's "Rolling in the Deep" left no doubt as to where the beat lay, and drummer Bernard Purdie's kickdrum accents on Bucky Pizzarelli’s Swing Live (24/96 FLAC, Chesky/HDtracks) really popped.
Finally, the M51 was capable of throwing a soundstage that extended past my speakers to the left and right. The placement of instruments and voices along that continuum was stable and well defined. Those images began just behind the speaker plane, but with little variation in depth. With the Mozart album, Brautigam’s piano was squashed in among the orchestra. With the greater space captured on Ole Bull’s Concerto Fantastico (24/192 FLAC, 2L/2L), the M51 layered the solo violin in front of the orchestral strings, which were in front of the brass, but these distinctions were not great and any sense of hall ambience was lost. When these positional cues are on a recording, I feel it is the responsibility of a high-end DAC not to obscure them. If, on the other hand, you primarily listen to studio recordings that lack a multidimensional soundstage, this criticism of the M51’s performance may not be terribly relevant.
Comparisons
Earlier this year, I reviewed the Resonessence Labs Invicta DAC ($3995), based on the Sabre 9018 from ESS Technologies and designed by some of the people who worked on that chip. The Invicta doesn’t support audio over HDMI (that capability may be added in future firmware), but it has a number of other features the M51 lacks. The Invicta’s two headphone outputs are of very high quality, and their volume levels can be independently controlled. The Resonessence also has an SD card slot that allows for direct playback of music stored in the WAV and AIFF formats, with some minimal capacity for navigating the card’s contents. The Invicta’s casework is assembled from precision-machined pieces of anodized aluminum that fit together with such close tolerances that the component almost seems as if hewn from a single block. The rear-panel inputs and outputs are of extremely high quality, and each is galvanically isolated from the chassis. Similar attention was given to the internal circuit layout, and the Invicta is powered by a customized toroidal transformer. There’s nothing wrong with the look or feel of the NAD, but the Resonessence is built to a higher standard. Its additional features and superior build quality may or may not matter to you, but they go a long way toward justifying its higher price.
The Invicta offers the choice of two digital reconstruction filters, but I’ll concentrate this comparison on the slow-rolloff option, which I generally found more compelling. With this filter, the Invicta created a holographic soundstage that extended far outside my speakers and possessed a staggering degree of depth. Each sound source was precisely placed within that space, and the reverberation trails around everything, from a single plucked string to a dense piano chord to a larger collection of instruments or voices, placed those sources within a distinct acoustic environment -- when one had been captured on the recording in the first place. The Invicta’s bass was extended, with great control and impact that supported the greater sense of space and made for a more visceral listening experience than with the M51. Though there was no obvious rolloff in the highest frequencies, the overall balance was a bit dark. (It was dead neutral with the fast-rolloff setting.)
In describing the Invicta’s sound in my review, I used the words smooth and relaxed; I also said it was forgiving of poor recordings. I would still characterize the Invicta that way, but it’s none of those things to the extent that the NAD M51 was. The Invicta’s high frequencies are more refined than those of the M51, giving a more complete picture of each instrument’s harmonic structure and better clarity to things like cymbals and triangles. On the other hand, the NAD’s softer highs will make even the most overcooked albums sound inoffensive. There was a difference to their smoothness through the midband as well. Listening to Willie Nelson and Wynton Marsalis’s Two Men with the Blues (CD, EMI 5 04454 2), I noted in my review of the Invicta that Nelson’s voice "was slightly muted by the Invicta’s Slow filter, as if Nelson had taken a step back from the microphone or was coming down with a slight cold." The NAD placed his voice more upfront with all of its twang, but left out some of its texture. Though the M51 was good at uncovering the incidental sounds that often make it onto recordings, the Invicta was a little better. Finally, I noted a slightly damped character in the Invicta’s reproduction of transients -- it made pianos, for example, sound a bit less lively than they should. Transients through the M51 were a little rounded, but still felt less constrained. Although I can imagine some listeners preferring the NAD’s warmer, extra-relaxed sound, overall, the nod for higher fidelity goes to the more expensive Invicta.
I usually extract digital data from my computer by connecting its coaxial digital output to my Grace Design m902 DAC/headphone amplifier. The m902’s USB input is limited to 48kHz and is highly prone to jitter, but the current model, the m903 ($1895), includes an asynchronous USB input that accepts sample rates up to 192kHz. Like the Invicta, the m902 has many more features than the M51, including an excellent headphone amplifier and two analog inputs, but no HDMI.
Like the NAD, the Grace is also a little warm through the midbass and midrange, but its high frequencies are less forgiving. On the downside, if a recording is edgy in the highs, the m902 will treat it less kindly than the M51. With properly recorded and mastered material, the m902 generally does a better job of rendering instruments’ upper harmonics. With standard-resolution sources, those more revealing highs could cut both ways. On the Marsalis-Nelson CD, when Marsalis’s trumpet shouts into the microphone, the m902 reproduces its overtones more realistically -- but, after all, it’s a sound that’s rather in-your-face. The M51 took a more subdued approach that traded vibrancy for comfort.
Through the Grace, the triangle in the second movement of Mahler’s Symphony No.3, with the Chicago Symphony under Bernard Haitink (CD, CSO Resound CSOR 901) -- as well as the triangle in the recordings of Dvorák’s Cello Concerto and Slavonic Dances with Adrian Leaper and the Gran Canaria Philharmonic Orchestra (CD, Arte Nova 74321 34054 2) -- rang out more cleanly above the orchestra, but with the stunted quality that has been common among DACs over the past decade. The NAD forwent that artificiality, but didn’t allow the sound to float free of its surroundings as it does in real life. It took players like the Resonessence Labs Invicta and the Ayre C-5xeMP to make that shimmering quality sound natural. As I moved to recordings made at higher sample rates, the m902 rewarded me with even greater verisimilitude; but whether I played high-resolution files or those from standard "Red Book" CDs, the M51 sounded pretty much the same.
Though I don’t think the Grace’s bass extends any deeper than the NAD’s, it’s better defined. That means a more forceful attack for kick drums, and a better separation of the sound of bass instruments from their surrounding acoustic environments. The latter may have been, at least in part, responsible for the Grace’s better rendering of recorded ambience. The m902’s soundstage wasn’t quite as wide as the M51’s, but it was deeper, with more explicit relationships in the positions of instruments. But while the Grace bested the NAD in this regard, it was no match for the Resonessence in the creation of huge, holographic soundscapes.
The M51 was very smooth and fluid in its presentation, the m902 crisper and more precise. Not only was the piano in the Mozart recording better separated, spatially, from the orchestra, but the ensemble sounded more deliberate in their performance -- which made the music more interesting. In Brautigam’s recording of Mendelssohn’s Lieder ohne Worte (24/96 FLAC, BIS/eclassical), the solo piano had much more percussive attack in the faster songs through the Grace, and a more realistic sound of hammers hitting strings, than the rounder-sounding NAD. Jazz recordings were a little snappier, and rock had a little more drive. The trade-off for all of this precision is that the Grace can sometimes sound a touch mechanical -- the NAD never did. The m902 delivers more of what’s on the recording, but I know that some listeners will prefer the more laid-back sound of the M51.
Conclusions
The DAC market is a crowded place. To make any headway, a new entrant -- even one from a thoroughly established brand like NAD -- needs to offer something special. Feature-wise, the Masters M51 matches its competition, and ups the ante with those two HDMI inputs and its pass-through facility, making it the only high-end DAC of which I’m aware that really fits in the two-channel home-theater space. It looks at home with other modern hi-fi components, and, of course, it’s the perfect match to NAD’s forthcoming Masters M50 digital music player and Masters M52 storage vault.
The M51’s sound, too, is something a bit different. Other DACs take a tighter hold on the music, tease out more detail, or create a better-defined soundstage. What the Masters M51 offers is a sound that’s smooth, laid-back, and always pleasant, no matter what you throw at it. Its slight favoring of the midrange imbues the sound with just a hint of extra warmth. For many listeners, such a combination is a recipe for audio bliss.
. . . S. Andrea Sundaram
andreas@soundstagenetwork.com
Associated Equipment
- Digital source -- Ayre Acoustics C-5xeMP universal stereo player
- Amplifier -- Graaf GM-50
- Speakers -- Esoteric MG-10
- Computer -- Custom Windows Vista laptop
- Headphones -- Stax SR-507, Ultrasone Pro 2900, HiFiMan HE-500
- Headphone amplifiers -- Woo Audio GES, Grace Design m902
- Interconnects -- Nordost Red Dawn LS, DH Labs Revelation, QED Silver Spiral
- Speaker cables -- DH Labs Q-10
- Power conditioner -- Equi=Tech Son of Q
NAD Masters M51 Direct Digital Digital-to-Analog Converter
Price: $1999 USD.
Warranty: Two years parts and labor.
NAD Electronics International
633 Granite Court
Pickering, Ontario L1W 3K1
Canada
Phone: (905) 831–6555
Fax: (905) 837-6357
Website: www.nadelectronics.com
